CVT-100

Fast Ethernet Fiber Media Converter

CVT-100 series media converter are the Fast Ethernet 10/100Base-TX to 100BaseFX media converter.

The CVT-100 series media converter converts traditional twisted-pair RJ-45 cable into various fiber media including multi-mode, single-mode, SC/ST/MR connector, or bi-directional WDM. The traditional transmission distance of 100 meter over RJ-45 copper can be greatly extended via fiber

CTSystems
Plug-and-play
Easy installation where complex configurations are not required
CTSystems
Link Alarm
If TP or fiber port is down during operation, the other port will automatically shutdown to alert the user
Model
Info
Version
Download File
CVT-100BTFX
Manual

V4.1

CT System Downloads
CVT-100W2X
Manual

V4.1

CT System Downloads
CVT-100
Datasheet

A03

CT System Downloads
ModelFiber PortTP Port
Speed (Mbps)TypeConnectorDistancePortSpeed (Mbps)Port
CVT-100BTFC100MMSC2km110/1001
CVT-100BTFT100MMST2km110/1001
CVT-100BTFC(SM-30)100SMSC30km110/1001
CVT-100W2A(SM-20)100WDMSC20km110/1001
CVT-100W2B(SM-20)100WDMSC20km110/1001
