FOS-3148

48-Port Managed Full Gigabit Ethernet Fiber Switch

FOS-3148 is a layer2+ gigabit access switch equipped with 44 dual-speed SFP slots and 4 combo uplink ports (10/100/1000Mbps RJ-45 + 100/1000Mbps SFP slots).

All SFP slots can accommodate wide range of SFP transceivers including single-mode, WDM or CWDM transceivers. FOS-3148 is perfect for service providers and enterprises who plan to implement FTTX or Metro Ethernet networks, with further spanning into triple-play service. Datasheet

CTSystems
Loop Detection
Automatically prevents the loop events from causing congestion in the network and keeps your service stable
CTSystems
DHCP Auto Provisioning
Automatically upgrades the firmware and configuration from DHCP server to save the maintenance cost
CTSystems
Dual Rate Fiber
Automatically senses and adjusts the fiber speed when changes are made in the network environment, providing a longer lifespan for the product
CTSystems
Power Redundancy
Keeps the device working when facing unexpected damage on power modules
CTSystems
Power Down Trap
Lets the device send a last message to the NOC when power is shut off and saves costs on deploying human resource for trouble shooting
CTSystems
IPv4/IPv6 Dual Stack
Supports both IPv4 and IPv6, saving your costs when transitioning from IPv4 to a IPv6 network
CTSystems
Flexible IPTV Deployment
Designed with rich functions in facilitating multimedia streaming and provides a stable IPTV service with high quality
CTSystems
Battery Backup
Enables your service to run smoothly under power outage situations
CTSystems
Dual Image
Prevents your device to die from firmware upgrade failures
CTSystems
Intelligent Diagnostics
Allow system operational monitoring in real-time, and instantly fault-identify SFF-8472-specification-compatible optical modules according to user-defined threshold parameters.
Model
Info
Version
Download File
FOS-3148
Manual

V0.93

CT System Downloads
FOS-3148
Manual (NMS)

V0.92

CT System Downloads
FOS-3148
Datasheet

A07

CT System Downloads
ModelDownstream PortsUplink portsSupport Power SourceOptional battery backup
Speed (Mbs)PortsTypeSPeed (Mbps)PortsType
FOS-3148-1A100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 1 Internal AC
FOS-3148-2A100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 2 Internal AC
FOS-3148-1D100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 1 Internal DC
FOS-3148-2D100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 2 Internal DC
FOS-3148-1AD100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 1 Internal AC and 1 Internal DC
FOS-3148-BAT-1A100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 1 Internal ACV
FOS-3148-BAT-P-1A100/100044SFP100/10004Combo (SFP+RJ-45)Fixed 1 Internal AC with ProtectorV
